Presence detector - Professional Line

Dual HF COM1 (on/off) / Concealed wiring

Product Code: 002978

Twice as vigilant! High-frequency corridor sensor Presence Control PRO Dual HF COM1 for indoors, ideal for passageways and long corridors, installation height up to 3.5 m, for switching light 'ON' and 'OFF', DUAL-HF technology for detecting radial movement over up to 20 m in two directions, detection regardless of temperature, HF-sensor technology detects movement through glass, wood and stud walls, switches light 'ON' almost instantly.

Product variants

A corridor sensor that points the way. Both in technology and design.

The Dual HF corridor sensor works with high-frequency technology that's particularly advanced. The system is fitted with 2 sensors, with each covering one corridor direction. Both of them together cover a good 20 metres in walking direction - for complete and reliable detection without blind spots. Tangential reach is deliberately limited to corridor width so as to avoid detecting movements behind closed doors, for instance.

high frequency sensor 360°

max. 20 x 3 m

max. 2000 W

IP20

ideal 2,5 - 3,5 m

indoor sensor

IQ-mode

Teach mode

energy saving

Application, place: Indoors
Installation: Concealed wiring
Detection angle: 360 °
Reach, tangential: 20 x 3 m (60 m²)
Mounting height max.: 3,50 m
Version: COM1 - Concealed wiring
Article number: 002978
PU1, net weight: 0,2 kg
Interconnection via: Cable
Package content: 1

General

Dimensions (L x W x H)	74 x 120 x 120 mm
Manufacturer's Warranty	5 years
Settings via	Remote control, DIP switches, Potentiometers, Smart Remote
With remote control	No
Version	COM1 - Concealed wiring
PU1, EAN	4007841002978
Type	Presence detector
Application, place	Indoors
Application, room	corridor / aisle, Indoors
Colour	white
Colour, RAL	9010
Package content	1

Fixation / mounting

Includes corner wall mount	No
Installation site	ceiling
Installation	Concealed wiring, Ceiling

Housing

IP-rating	IP20
Ambient temperature	from -25 up to 55 °C
Material	Plastic

Electrical equipment

Mains power supply	230 V / 50 – 60 Hz
Fluorescent lamps, electronic ballast	1500 W
Fluorescent lamps, uncorrected	1000 VA
Fluorescent lamps, series-corrected	1000 VA
Fluorescent lamps, parallel-corrected	1000 VA
Switching output 1, low-voltage halogen lamps	2000 VA
LED lamps < 2 W	100 W
LED lamps > 2 W < 8 W	300 W
LED lamps > 8 W	600 W
Capacitive load in μF	176 µF

General information

Article number	002978
European Article Number (EAN)	4007841002978
Detection angle	Aisle, 360 °
Angle of aperture	140 °
Transmitter power	< 1 mW

Sensor technology

Technology, sensors	High frequency, Light sensor
Mounting height	2,50 – 3,50 m
Mounting height max.	3,50 m
Optimum mounting height	2,8 m
HF-system	5,8 GHz
Detection	also through glass, wood and stud walls
Sneak-by guard	Yes
Capability of masking out individual segments	No
Electronic scalability	Yes
Mechanical scalability	No
Reach, radial	20 x 3 m (60 m²)
Reach, tangential	20 x 3 m (60 m²)

Functions

Functions	Normal / test mode, Semi-/fully automatic, Pushbutton / switch mode, Manual ON / ON-OFF
Twilight setting	10 – 1000 lx
Time setting	30 s – 30 Min.
Basic light level function	No
Main light adjustable	No
Twilight setting TEACH	Yes
Constant-lighting control	No

Connection

Interconnection	Yes
Type of interconnection	Master/master, Master/slave
Interconnection via	Cable
Interconnection, number	max. 10 sensors
