Presence detector - Professional Line

DualTech COM1(on/off) / In-ceiling installation

Product Code: 079574

The best of both worlds. Combined in one detector. Ultrasonic presence detector DualTech, ideal for offices, conference rooms and class rooms. 36 sq.m. presence zone, ultrasonic technology provides reliable detection behind objects regardless of temperature, additional detection capability with PIR technology, electronic adjustment for ultrasonic reach, COM1 for switching light ON and OFF.

Pairs well with
The best of both worlds. Combined in one detector.
The best of both worlds. Combined in one detector.

The best of both worlds. Combined in one detector.

Offices, conference rooms and classrooms come with their own particular spatial situations that don't exactly make it easy to provide efficient lighting control. That's why we have developed an innovative 360° detector with a 28 sq.m. presence detection zone that uses the best qualities of two leading technologies. This way, the DualTech can also detect movements without visual contact with the sensor. PIR technology provides additional detection capabilities. And maximum reliability.











The best of both worlds. Combined in one detector.

Offices, conference rooms and classrooms come with their own particular spatial situations that don't exactly make it easy to provide efficient lighting control. That's why we have developed an innovative 360° detector with a 28 sq.m. presence detection zone that uses the best qualities of two leading technologies. This way, the DualTech can also detect movements without visual contact with the sensor. PIR technology provides additional detection capabilities. And maximum reliability.











The best of both worlds. Combined in one detector.

Offices, conference rooms and classrooms come with their own particular spatial situations that don't exactly make it easy to provide efficient lighting control. That's why we have developed an innovative 360° detector with a 28 sq.m. presence detection zone that uses the best qualities of two leading technologies. This way, the DualTech can also detect movements without visual contact with the sensor. PIR technology provides additional detection capabilities. And maximum reliability.











The best of both worlds. Combined in one detector.

Offices, conference rooms and classrooms come with their own particular spatial situations that don't exactly make it easy to provide efficient lighting control. That's why we have developed an innovative 360° detector with a 28 sq.m. presence detection zone that uses the best qualities of two leading technologies. This way, the DualTech can also detect movements without visual contact with the sensor. PIR technology provides additional detection capabilities. And maximum reliability.











Icon

ultrasonic sensor 360°

Icon

infrared sensor 360°

Icon

max. Ø 6 m presence

Icon

max. 2000 W

Icon

IP20

Icon

ideal 2,5 - 3,5 m

Icon

indoor sensor

Icon

Teach mode

  • Application, place: Indoors

  • Installation: In-ceiling installation

  • Detection angle: 360 °

  • Reach, tangential: Ultrasonic: Ultraschall: Ø 10 m (Ultraschall: 79 m²)

  • Mounting height max.: 3,50 m

  • Version: COM1 - in-ceiling installation

  • Article number: 079574

  • PU1, net weight: 0,225 kg

  • Interconnection via: Cable

  • Package content: 1

Product dimension

General

Dimensions (L x W x H)103 x 120 x 120 mm
Manufacturer's Warranty5 years
Settings viaRemote control, DIP switches, Potentiometers, Smart Remote
With remote controlNo
VersionCOM1 - in-ceiling installation
PU1, EAN4007841079574
TypePresence detector
Application, placeIndoors
Application, roomclassroom, one-person office, open-plan office, conference room / meeting room, duty room, recreation room, Indoors
Colourwhite
Colour, RAL9010
Package content1

Fixation/ mounting

Includes corner wall mountNo
Installation siteceiling
InstallationIn-ceiling installation, Ceiling

Housing

IP-ratingIP20
Ambient temperaturefrom -25 up to 55 °C
MaterialPlastic

Electrical equipement

Mains power supply220 – 240 V / 50 – 60 Hz

General information

Article number079574
European Article Number (EAN)4007841079574
Detection angle360 °
Angle of aperture180 °

Sensor technology

Sensor Technology 2passive infrared
Technology, sensorsUltrasonic, passive infrared, Light sensor
Mounting height2,50 – 3,50 m
Mounting height max.3,50 m
Optimum mounting height2,8 m
Ultrasonic technology40 kHz
Sneak-by guardYes
Capability of masking out individual segmentsNo
Electronic scalabilityYes
Mechanical scalabilityNo
Reach, radialUltrasonic: Ultraschall: Ø 10 m (Ultraschall: 79 m²)
Reach, tangentialUltrasonic: Ultraschall: Ø 10 m (Ultraschall: 79 m²)
Reach, presenceUltrasonic: Ultraschall: Ø 6 m (Ultraschall: 28 m²)
Reach, radial 2passive infrared: Passiv Infrarot: Ø 4 m (Passiv Infrarot: 13 m²)
Reach, tangential 2passive infrared: Passiv Infrarot: Ø 8 m (Passiv Infrarot: 50 m²)
Reach, presence 2passive infrared: Passiv Infrarot: Ø 4 m (Passiv Infrarot: 13 m²)
Switching zones520 switching zones

Functions

FunctionsNormal / test mode, Semi-/fully automatic, Pushbutton / switch mode, Manual ON / ON-OFF
Twilight setting10 – 1000 lx
Time setting30 s – 30 Min.
Basic light level functionNo
Main light adjustableNo
Twilight setting TEACHYes
Constant-lighting controlNo

Connection

InterconnectionYes
Type of interconnectionMaster/master, Master/slave
Interconnection viaCable
Interconnection, numbermax. 10 sensors

General information

Product categoryPresence detector
