The savings apply in comparison to using a conventional LED light without motion detector with the same power for an average of 10 hours of continuous light a day. In comparison, the STEINEL LED light with motion detector only lights up for an average of 2 hours at night because the light is only switched on when movement is detected.



Icon

30 years (Ø 4,5h / day)

Icon

3000K warm-white

Icon

Infrared sensor ideal 12 x 12 m

Icon

Scalable in every direction

Icon

IP54

Icon

2 - 2000 lux

Icon

5 sec - 30 min

Icon

Light source not exchangeable

Icon

Control gear not exchangeable

  • Application, place: Outdoors

  • Installation: Surface wiring

  • Article number: 035440

  • PU1, net weight: 0,89 kg

  • Luminous flux total product: 1000 lm

  • Colour temperature: 3000 K

  • With motion detector: Yes

  • Output: 9,8 W

  • Package content: 1

Product dimension

General

Dimensions (Ø x H)310 x 69 mm
With lampYes, STEINEL LED system
Manufacturer's Warranty3 years
Settings viaPotentiometers
With remote controlNo
Versionwhite
PU1, EAN4007841035440
Application, placeOutdoors
Application, roomcorridor / aisle, function room / ancillary room, stairwell, outdoors, front door, courtyard & driveway, Indoors
Colourwhite
Package content1

Fixation/ mounting

Installation siteceiling

Housing

Impact resistanceIK07
IP-ratingIP54
Protection classII
Ambient temperaturefrom -20 up to 35 °C
Housing materialPlastic
Cover materialPlastic, structured

Electrical equipement

Mains power supply220 – 240 V / 50 – 60 Hz
Output9,8 W

Sensor technology

Mounting height max.6,00 m
Slave modeselectableNo
Sneak-by guardYes
Capability of masking out individual segmentsYes
Electronic scalabilityNo
Mechanical scalabilityYes
Reach, detailReach adjustable from 2 - 8 m in 4 directions (90° in each)
Reach, radial4 x 4 m (16 m²)
Reach, tangential16 x 16 m (256 m²)
Optimum mounting height2,8 m
Detection angle360 °

Luminaire

Photo-cell controllerYes
Luminous flux total product1000 lm
Measured luminos flux (360°)1000 lm
Total product efficiency102 lm/W
Colour temperature3000 K
Colour variation LEDSDCM3
LampLED cannot be replaced
LED life expectancy (max. °C)50000 h
Service life LED L70B50 (25°)> 60000 h
Basewithout
LED cooling systemPassive Thermo Control
Soft light startYes
Continuous lightselectable, 4h
Colour Rendering Index CRI= 82

General information

Article number035440
European Article Number (EAN)4007841035440
Basic light level function in per cent10 %
Basic light level function percentage, from10 %
Basic light level function percentage, up to10 %

Functions

Twilight setting2 – 1000 lx
Time setting5 s – 30 Min.
Basic light level functionYes
Basic light level function time10/30 min, all night
Main light adjustableNo
Twilight setting TEACHNo

Connection

InterconnectionNo

General information

Product categorySensor-switched LED outdoor light
