See our R-Series in action. With the most intelligent sensor luminaire system of our time, you can combine optimal light with the simplest installation and networking. Warm white and neutral white versions with up to 3200 lumens. Backlight, basic light, battery-operated emergency light, flexible run-on time and networking into area groups. And all this can be set via APP.





Sensor light 4.0

Convinces with high-precision HF sensor, outstanding efficiency and absolutely uniform light distribution. With two housing shapes (round/cornered) and five sizes, the RS PRO R series plus offers the right lighting solution for every taste and need up to max. 3200 lumens - in neutral or warm white light. Basic and main light levels can be conveniently adjusted via smartphone. The backlight, which can be optionally switched on via app, creates a particularly pleasant lighting atmosphere. The convenient neighbourhood group function always ensures seamlessly efficient lighting. In the event of a power failure, the optional battery-powered emergency lighting module reliably provides sufficient light. Alternatively, emergency lighting operation is also possible via connection to central battery systems. Conclusion: Whether for new buildings or renovations - the RS PRO R series plus is by far the most complete lighting solution of our time.



Connected Lighting in the application.

The combination of sensor technology, efficient LED light, networking and intelligent control ensures needs-based switching and creates greater convenience and safety for users. The system is also unbeatably easy to install thanks to tool-free commissioning via the Steinel Connect app. A 5-year manufacturer's guarantee, BEG eligibility and savings of up to 95% on electricity and maintenance costs round off the benefits for everyone involved.



More functions

The RS PRO R series plus with 4 lighting functions - basic light, backlight, dimmable main light and emergency light - which can be adjusted without a ladder via an app, is the most intelligent and convenient digital sensor luminaire system on the market - and is a source of great enthusiasm among planners, installers and building owners. The RS PRO R-Series plus wall and ceiling luminaire skilfully combines clear, universally applicable design and optimal light with extremely simple installation and networking via app. Thanks to modern Bluetooth technology as well as update and IoT capability, the digital sensor luminaire system stands for maximum future security.



This is how you save.

The savings apply in comparison to using a conventional LED light without motion detector with the same power for an average of 10 hours of continuous light a day. In comparison, the STEINEL LED light with motion detector only lights up for an average of 2 hours at night because the light is only switched on when movement is detected.



Overview

See our R-Series in action. With the most intelligent sensor luminaire system of our time, you can combine optimal light with the simplest installation and networking. Warm white and neutral white versions with up to 3200 lumens. Backlight, basic light, battery-operated emergency light, flexible run-on time and networking into area groups. And all this can be set via APP.





Sensor light 4.0

Convinces with high-precision HF sensor, outstanding efficiency and absolutely uniform light distribution. With two housing shapes (round/cornered) and five sizes, the RS PRO R series plus offers the right lighting solution for every taste and need up to max. 3200 lumens - in neutral or warm white light. Basic and main light levels can be conveniently adjusted via smartphone. The backlight, which can be optionally switched on via app, creates a particularly pleasant lighting atmosphere. The convenient neighbourhood group function always ensures seamlessly efficient lighting. In the event of a power failure, the optional battery-powered emergency lighting module reliably provides sufficient light. Alternatively, emergency lighting operation is also possible via connection to central battery systems. Conclusion: Whether for new buildings or renovations - the RS PRO R series plus is by far the most complete lighting solution of our time.



Connected Lighting in the application.

The combination of sensor technology, efficient LED light, networking and intelligent control ensures needs-based switching and creates greater convenience and safety for users. The system is also unbeatably easy to install thanks to tool-free commissioning via the Steinel Connect app. A 5-year manufacturer's guarantee, BEG eligibility and savings of up to 95% on electricity and maintenance costs round off the benefits for everyone involved.



More functions

The RS PRO R series plus with 4 lighting functions - basic light, backlight, dimmable main light and emergency light - which can be adjusted without a ladder via an app, is the most intelligent and convenient digital sensor luminaire system on the market - and is a source of great enthusiasm among planners, installers and building owners. The RS PRO R-Series plus wall and ceiling luminaire skilfully combines clear, universally applicable design and optimal light with extremely simple installation and networking via app. Thanks to modern Bluetooth technology as well as update and IoT capability, the digital sensor luminaire system stands for maximum future security.



This is how you save.

The savings apply in comparison to using a conventional LED light without motion detector with the same power for an average of 10 hours of continuous light a day. In comparison, the STEINEL LED light with motion detector only lights up for an average of 2 hours at night because the light is only switched on when movement is detected.



Icon

36 years (Ø 4,5h / day)

Icon

Settings via App

Icon

3000K warm-white

Icon

high frequency sensor 360°

Icon

max. 10 m

Icon

2 - 2000 lux

Icon

IP40

Icon

Light source not exchangeable

Icon

Control gear not exchangeable

  • Application, place: Indoors

  • Installation: Surface wiring

  • Article number: 067717

  • PU1, net weight: 1,088 kg

  • Luminous flux total product: 992 lm

  • Colour temperature: 3000 K

  • With motion detector: Yes

  • Interconnection via: Bluetooth Mesh

  • Output: 8,5 W

  • Package content: 1

Product dimension

General

Dimensions (Ø x H)300 x 55 mm
With lampYes, STEINEL LED system
With motion detectorYes
Manufacturer's Warranty5 years
Settings viaBluetooth
With remote controlNo
Versionwarm white
PU1, EAN4007841067717
Application, placeIndoors
Application, roomcorridor / aisle, changing room, function room / ancillary room, kitchenette, stairwell, Indoors
Colourwhite
Package content1
Fuse protection B1046
Fuse protection B1674
Fuse protection C1077
Fuse protection C16122

Fixation / mounting

Includes sheet of self-adhesive numbersNo
Installation sitewall, ceiling
InstallationWall, Ceiling, Surface wiring

Housing

Impact resistanceIK07
IP-ratingIP40
Protection classII
Ambient temperaturefrom -20 up to 40 °C
Housing materialPlastic
Cover materialPC, opal
IP-rating, ceilingIP40

Electrical equipment

Mains power supply220 – 240 V / 50 – 60 Hz
Power consumption0,3 W
Output8,5 W
Starting current, maximum13 A

Sensor technology

Mounting height max.4,00 m
HF-system5,8 GHz
Slave mode selectableYes
Detectionalso through glass, wood and stud walls
Capability of masking out individual segmentsYes
Electronic scalabilityYes
Mechanical scalabilityNo
Reach, radialØ 10 m (79 m²)
Reach, tangentialØ 10 m (79 m²)
Detection angle360 °

Luminaire

Photo-cell controllerYes
Luminous flux total product992 lm
Total product efficiency117 lm/W
Colour temperature3000 K
Colour variation LEDSDCM3
LampLED cannot be replaced
Basewithout
LED cooling systemPassive Thermo Control
Soft light startYes
Continuous lightselectable
Lifetime LED according to IEC-62717 (L70)100,000 h
Lifetime LED according to IEC-62717 (L80)74,000 h
LED service life according to IES TM-21 (L70)>60,000 h
Lifetime LED according to IES TM-21 (L80)>60,000 h
Colour Rendering Index CRI= 82
Photobiological safety in accordance with EN 62471RG1

General information

Article number067717
European Article Number (EAN)4007841067717
Transmitter power< 1 mW
Basic light level function in percent0 – 100 %
Angle of aperture160 °

Functions

FunctionsGroup parameterisation, Manual ON / ON-OFF, Neighbouring group function, Backlight, Orientation light, Connection to central battery systems, Adjustable fade time when switching on and off, Free selection of the light value in a luminaire group, Encrypted communication, Motion sensor, Light sensor, Master/slave override, Presence function
Twilight setting2 – 2000 lx
Time setting5 s – 60 Min.
Basic light level functionYes
Basic light level function, detailLED Backlight
Basic light level function time1-60 min
Main light adjustable0 - 100 %
Twilight setting TEACHYes

Connection

InterconnectionYes
Type of interconnectionMaster/master
Interconnection viaBluetooth Mesh

General information

Product categorySensor-switched LED indoor light
